Product Description
• Standard height of curtain formed : UP TO 15 FT • Speed Maximum Air Velocity at Nozzle Discharge (CFM) : High 23 m/s • Noise level at a distance of 10’ from the curtain Db : 55 DB • No. of Blower : 2 BLOWERS • No. of Motors : (1 Motor) • Phase : Single Phase • RPM : 1400 RPM • Air Curtain thickness : 1 mm Body Material : ALL SS 304 STEEL BODY • motor No. of Shaft : Double Shaft • Blower : ALUMINIUM • Electrical Motor: Double shaft • BLOWER : Aliminium • BLOWER SIZE : 9” x 8” • ELECTRICAL MOTOR: MNC BRAND • Maintenance Points for oiling : No require • .%Insect / Dust : 80% • Air Curtain Operation : Electrical • Weight (Approx) Kgs.30 • Motor HP : 0.50 HP & ½ HP • Motor winding : Cooper winding • Bearing : 2 RS sheel Bearing
Model MEI 400 C S 304 (4FT)
Height UP TO 15 FT
Price 0
Weight 40KG
